“Research International” USA offers various types of Bio-Sample collection products which can be configured for variety of applications.

SASS® 2300 Wetted Wall Cyclonic Sampler

1. Collects 1 to 10 micron diameter respirable particles into a 4 to 5 cc liquid volume: 50% @ 1.5 - 1.8 m
2. Ideal for collecting delicate organisms for culturing
3. Air-to-liquid concentration ratio is 750,000 after 10 minute sampling
4. 325 LPM sampling rate; 30,000 hour fan life

SASS 3100 – Dry Filter Aerosol Collector

1. Lightweight and portable- 2.8 kg w/bat.
2. 24-hour operation on battery power
3. Extremely high collection efficiencies for standard electret filter type:
   - 0.5 µm dia: 50%
   - 1.0 µm dia: 75%
   - 2.0 µm >dia: 90%
4. Ultra-high collection efficiency for radioactive aerosol filter type:
   >99% for >0.3 microns dia.
5. Operable from -40°C to 70°C
6. Programmable/digitally controllable

SASS 3010 Manual Particle Extractor

The SASS® 3010 is used to extract and transfer to a small fluid volume, aerosols captured by Research International’s electret filters. Captured particulates can be difficult to remove because induced dipole fields create a strong holding force and must be neutralized. Once particulates have been released, they must then be removed from within the fibrous filter matrix and collected in a small amount of sample fluid. These processes are efficiently performed in a matter of 1 to 2 minutes using the SASS 3010 Particle Extractor.
Extraction efficiencies have been found to be in the range of 70 to 80%.

SASS 4000 Concentrator & SASS 4100 Collector

1. The SASS 4000 is a highly efficient, high-volume aerosol concentration device.
2. The SASS 4100 is a highly efficient, two-stage filter-based aerosol collection device.
3. Typical application area which involve the monitoring or collection of airborne plant, animal or human pathogens.
4. 325 LPM sampling rate; 30,000 hour fan life

But aerosol sample analysis is frequently plagued by four problems –

1. The targeted pathogen is present at a very low concentration
2. The collection process involves too small an air sample to be statistically valid
3. The temperature is below freezing; and/or
4. Available bioassay methods are not sensitive enough.

SASS 4200 – Vehicle Mount High Volume Dry Aerosol Collector

1. Creates an aerosol concentrate from low-level atmospheric aerosols
2. Roof mountable- operable during vehicle movement
3. Very high sampling rate
4. High efficiency
5. Reliable-No moving parts other than the primary fan
6. Requires only 100-160 watts of electrical power
7. Compatible with most wet and dry lab samplers and bioanalyzers
8. Wide operating temperature range
9. Clog resistant

TacBio Bio-Aerosol Detector

1. The TacBio is a device designed to continuously monitor background biological aerosol levels.
2. The most common applications are as an alarm that signals when an unusual rise in the bio-aerosol background has occurred and/or as a trigger to turn on a sampler or bio-identifier
3. Developed by the U.S. Army as a rugged, portable aerosol bio-detector
4. Monitors bio-aerosol fluorescence excited by a UV LED that has a 20,000 to 30,000 hr life; stable to 85C
5. 1.2 LPM air pump; 40,000 hr life.
6. Electro-optics uses photon counting to minimize calibration drift
7. Communication: RS-232 or wireless
8. Windows software for setup/monitoring
9. Removable data card : 5 yr capacity
10. Will control RI air samplers and bio-identifiers
11. 24+ hour operation on battery; 4.8W
12. 8.8 pounds (4 kg)

TacBio V

TacBio V – is an integration of the latest digital photon bioaerosol detector technology with a 300 LPM sample collection module based on the electret filter based SASS 3100.

1. Light weight
2. UV photon counting technology
3. No consumables
4. 24-hour battery life
5. Wireless communications capable

BioHawk^TM Automated Air Sampler & Bio-identifier:

1. Field-portable militarized system for automated pathogen detection
2. Incorporates 325 LPM air sampler
3. 8-channel system
4. Based on disposable coupons: Assay times typically 15-20 mins.
5. All reagents on coupon
6. Can run 10 assays over 48 hours before coupon must be replaced
7. Weighs 26.7 lbs (12.1 kg) with battery and fluids

ANCAM 6100 Ticket Reader/ Reporter

1. Machine vision and pattern recognition provide consistent high sensitivity ticket assays.
2. The user is alerted to any abnormal coupon behavior.
3. Compatible with most tickets available now or in the future.
4. Single or multichannel ticket analysis supported.
5. Positive channels identified up to 3X earlier than with manual exams.
6. Images, calculations and GPS location are archived onboard.
7. Connects to the local cellular network: email results to headquarters.
8. A Map function lets users see where they are in the field.

VBAD 3600/3700 Robotic Bioassay System:

1. VBAD 3600 samples and monitors aerosols for pathogens.
2. VBAD 3700 samples and identifies pathogens in liquid samples.
3. Simple operation: 24 assay procedures can be performed without any human intervention.
4. Results are reported to a control PC.

Automated processes include:

1. Ticket transport
2. Precision sample transfer to single or multi-well tickets
3. Monitoring of assay progress: digital camera and software.
4. Confirmatory samples and set up for next assay automatically performed.

Wet fluid reservoirs provided. Optional glove box for pathogen containment
